Description
Overall Operating Weight |
8200KG |
Final Reducer |
Single Stage Final Reducer |
||
Transport Dimension |
Rated Loader of Axle |
8/18.5t |
|||
L*W*H (mm) |
5920×2250×3770 |
Transmission System |
|||
Wheel base |
2200mm |
Torque Converter |
|||
Min. Ground Clearance |
300mm |
Model |
YJ280 |
||
Bucket Capacity |
1.0m3 |
Type |
Single-stage Three Elements |
||
Breakout Force |
38KN |
Max. Efficiency |
84.4% |
||
Loading Lifting Capacity |
2500KG |
Inlet Pressure |
0．5Mpa |
||
Bucket Dumping Height |
2742mm |
Outlet Pressure |
1.1Mpa—1.3 Mpa |
||
Bucket Dumping Distance |
925mm |
Cooling Method |
Oil-cooling Pressure Circulation |
||
Digging Depth |
52mm |
Gearbox |
|||
Backhoe Capacity |
0.3 m3 |
Type |
Fixed Shaft Power Transmission |
||
Max. Digging Depth |
4082/4500mm |
Oil Pressure of Clutch |
1373Kpa—1569 Kpa |
||
Swing Angle of Excavator Grab |
190 |
Gears |
Two Gears Ahead, Two Gears Astern |
||
Max. Pulling Force |
39KN |
Max.Speed |
28Km/h |
||
Engine |
Tyre |
||||
Model |
YC4A105Z-T20 |
Model |
14-17.5/19.5L-24 |
||
Type |
In Line Direct injection Four-Stroke and Injection Combustion Chamber |
Pressure of Front wheel |
0.55Mpa |
||
Cylinder-Inside Diameter*Stroke |
4-102×120 |
Pressure of Back Wheel |
0.223Mpa |
||
Rated Power |
75KW |
Brake System |
|||
Rated Speed |
2200r/min |
Service Brake |
Air Over Oil Caliper Brake |
||
Min. Fuel Consumption |
≤242g/km.h |
External Type |
|||
Max.Torque |
≥410N.M |
Self-regulation |
|||
Displacement |
4.4L |
Self-balance |
|||
Steering System |
Emergency Brake |
Operation Power Implementing brake |
|||
Model of Steering Device |
BZZ5-250 |
Manual Operation Power Terminating Brake |
|||
Steering Angle |
±36 o |
Hydraulic System |
|||
Min. turning radius |
6581mm |
Digging Power of Excavator Grab |
46.5KN |
||
Pressure of the system |
12Mpa |
Digging Power of Dipper |
31KN |
||
Axle |
Bucket Lifting Time |
6．8S |
|||
Main Transmission Type |
Double Reduction |
Bucket Lowering Time |
3.1S |
||
Bucket Discharge Time |
2.0S |
||||
